Gutermann ZONESCAN 820
by Gutermann AG · 🇨🇭 Switzerland · Noise Loggers & Monitoring
VERIFIEDCorrelating Noise Logger (radio)
Radio-based correlating noise logger and long-standing flagship of the ZONESCAN fixed network family. Loggers record synchronised night-time noise and correlate in pairs for precise leak pinpointing; data is collected via repeater network or drive-by. Deployed at scale in projects such as the 5,500-logger AMI-integrated network in Grand Lyon, France that helped reduce NRW from 21% to below 15%.
Technical specifications
| Meter / product type | Correlating radio leak noise logger |
| Application | Lift & shift / drive-by / fixed-network leak detection |
| Detection method | Logs noise level and sound-frequency spectrum; correlation/cross-correlation between loggers; auto-filter rejects non-leak noise to avoid false positives |
| Sensor type | Acoustic noise sensor (+ 3D motion & humidity sensors) |
| Communication | Proprietary bi-directional radio (transmits under chamber/valve lids); drive-by via Commlink + Android; OTA firmware upgrade |
| Protection class (IP) | IP68 |
| Housing material | Stainless steel housing |
| Dimensions / weight | 100 mm x Ø 41.5 mm, 310 g |
| Operating temperature | -30 to +70 degC |
| Battery life | Typically over 5 years (Li-cell, authorised replacement) |
| Power / battery | Field-replaceable battery; firmware-optimised consumption; fuel-gauge chip |
| Outputs / software | ZONESCAN SMART app (auto-filter; OpenStreetMap/Google Maps); Gutermann cloud; KML import |
| Accessories | Antenna options (RSMA); ZONESCAN Commlink |
| Mounting / installation | Magnet-mounted in chamber / on pipe |
| Deployment type | Modular - lift & shift, drive-by or fixed network |
✓ Verified from manufacturer datasheet. View datasheet →
